Place of Origin:
China
Brand Name:
ENMESI
Certification:
CE,FCC,ROHS
Model Number:
E633
Split Glasses HD Close Eye Virtual Reality Head Mounted Display Mobile Cinema 3D Video Glasses
The head-mounted display is also known as the glasses type display, and the mobile theater.
The working principle is to enlarge the image on the ultra-fine display through the optical system (mainly precision optical lens), and then present the large-screen image in the viewer's eyes. Since it looks like glasses, so also known as video glasses.
Video glasses solves perfectly the contradiction between portable audio and video equipment and powerful ultra-portable electronic equipment, that is the contradiction between delicate volume and big display.
Therefore, in the future, it will certainly be widely used more and more.
Product description
The E633 is split glasses, it has smart glasses and control host ( It can also connect mobile phones ect) .
User manual
Product details (3D smart glasses)
| Display Screen | LCOS Material |
| Screen size | 0.38 inch |
| Resolution | 1280*720*2 , PPI up to 3860 |
| Lens |
A group of multiple optical resin lenses,anti-blue light protective film |
| Diopter | -0.7D~0.7D adjustable |
| IPD | 58~68mm |
|
Eye relief |
18mm |
| Exit pupil | 7mm |
| FOV | 40° |
| Interface |
Type C 3.5mm stereophone |
|
Operational control |
Button |
|
Power consumption |
1.65W |
|
Dimension |
194x156x47 mm |
|
Net weight |
120g |
Product details (Control Host)
| CPU |
Quad core Cortex -A35 |
| GPU |
Mali-G31 GPU |
| RAM | 2GB |
| ROM |
16GB |
|
Storage expansion |
128GB TF card |
|
Multimedia |
Multi-format 1280x720/ 60fps video output |
|
WIFI |
2.4G+5G |
|
Battery |
3.7 V/ 4000mAh rechargeable lithium battery |
|
Charge |
DC 5V / 2A |
| Interface |
Micro USB Type C, TF card |
|
Operational control |
Button |
|
Power consumption |
1.7W |
|
Dimension |
194x68x14 mm |
| Net weight | 158g |
Product features
Product packing list
