Mini 2 Inch Screen FPV Goggles with 480×360 Resolution and 48 Channels for Drone Racing

Mini 2 Inch Screen FPV Goggles with 480×360 Resolution and 48 Channels for Drone Racing

fpv drone and goggles

fpv drone and goggles

Place of Origin:

Shenzhen,China

Brand Name:

ENMESI

Certification:

CE, ROHS, FCC,CCC

Model Number:

F6

Contact Us
Request A Quote
Product Details
Screen Size:
2"
Channel:
48 Channels
Screen Material:
TFT LCD
Resolution:
480*360
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
gift box packaging.Micro USB cable(1meter),charger(5V, 1A), user manual, warranty card, cleaning cloth, 2*rod antennas, gain 8dBi, clothing bag, headband,
Delivery Time
7 work days
Payment Terms
T/T,Western Union etc
Supply Ability
10000pcs/month
Product Description
480×360 Pix AV IN FPV Goggles Mini 2 Inch Binocular Screen 48 Channels
Product Overview

Mini 2 Inch Binocular Screen FPV Glasses 480×360 pix AV IN FPV Drone Goggles

FPV, known as "first person view," is an innovative way to operate screen-control models using remote-controlled aviation or vehicle models equipped with wireless camera backhaul devices.

Traditional remote control models are operated by holding a remote control while observing the distant model to control its posture and perform various actions. With the miniaturization of electronic devices, we can now install wireless video transmission equipment on models with limited volume and load capacity, enabling first-person perspective operation. This allows you to control your model aircraft or vehicle from the driver's viewpoint, experiencing the thrill of soaring through the sky or racing on the ground without physical risk.

Product Specifications
Screen Size 2 inch
Material TFT LCD
Resolution 480×360
FOV Field of view: 0/120 degrees (horizontal/vertical)
Power Consumption 1.5W-2.2W
Frequency 5.8GHz, 48CH
IPD 60-68mm (Adjustable)
Battery 3.7v 1000mAh Li-ion
Product Features
  • 300cd/㎡ High brightness for outdoor use
  • TFT LCD 2 inch 480×360 binocular screen
  • Ergonomic design, small size and light weight for comfortable wear
  • 48 channel automatic scanning diversity antenna receiver with built-in 1000mAh rechargeable lithium battery
  • Adjustable pupil distance (IPD: 60-68mm)
  • Extremely short delay, wide reception range, clear and smooth video
  • 0/120 (Vertical/horizontal) angle of view range for large screen enjoyment
User Manual
Download User Manual
48 Channel Frequency Table
Band CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
Band-A 5645 5665 5685 5705 5885 5905 5925 5945
Band-B 5740 5760 5780 5800 5820 5840 5860 5880
Band-C 5725 5745 5765 5785 5805 5825 5845 5865
Band-D 5733 5752 5771 5790 5809 5828 5847 5866
Band-E 5658 5695 5732 5769 5806 5843 5880 5917
Band-F 5362 5399 5436 5473 5510 5547 5584 5621
Our Services
  • Quick sample provision for evaluation
  • Custom mold development for unique designs, logos, and frames
  • Multiple model options for reference
  • Customized solutions based on specific requirements including size and frame color
  • 24-hour response time for product or pricing inquiries
  • 1-year warranty on active shutter glasses
  • Protection of sales territories, design concepts, and private information
  • Support for small order quantities
