PMMA Lens Glasses FPV Video Glasses 4.3 Inch 16/9 AV IN Input Short Delay FPV Drone Goggles

PMMA Lens Glasses FPV Video Glasses 4.3 Inch 16/9 AV IN Input Short Delay FPV Drone Goggles

drone fpv headset

hd fpv goggles

Place of Origin:


Brand Name:




Model Number:


Contact Us
Request A Quote
Product Details
Dual Antenna
5.8G & AV IN
Screen Size:
Less Than 30ms
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
gift box packaging, 1pcs:145*162*98(mm).Micro USB cable(1meter),charger(5V, 1A), user manual, warranty card, cleaning cloth, 2*rod antennas, gain 8dBi, clothing bag, headband, AV cable(40cm).
Delivery Time
7 work days
Payment Terms
T/T, Western Union etc
Supply Ability
Product Description

New 4.3 Inch AV IN Input FPV Drone Goggles Short Delay Adjustment PMMA Lens Glasses



Product features

  • The new F2 goggles offer a TFT 4.3 inch 480*272 HD screen.
  • 16:9 display scale, equipped with 48 channel automatic scanning diversity antenna receiver and built-in 2000mAh rechargeable lithium battery, cost-effective.
  • Ergonomic design, the same weight on both sides, each with a 1000mAh battery, small size and light weight, comfortable to wear.
  • The delay is extremely short, the reception range is wide, the watch video is clear and smooth.
  • 0/120 (Vertical/horizontal) angle of view range, large screen enjoyment.
  • 500cd/㎡of High brightness,for Outdoor.
  • DUO Design: Combines the best performance of a circular combination with the RX and allows two types of antennas at the same time, Omni directional / Straight Antenna.

Product Details:

Screen Size 4.3inch
Material TFT LCD
Resolution 480*272
FOV Field of view: 0/120 degrees (horizontal/vertical)
Power consumption 1.5W in HD mode, 2.3W in 5.8G mode
Channels 48channesl (6 bands *8 channels), support channel auto-searching
Battery 600mAh reachargeable Li-battery
Size 150mmX82mmX145mm
Weight 280g

 PMMA Lens Glasses FPV Video Glasses 4.3 Inch 16/9 AV IN Input Short Delay FPV Drone Goggles 0


1 ----- Power ON/OFF

2 ----- Power indicator light, turns blue after booting

3 ----- S, Channels switching

4 ----- AV, AV input interface

5 ----- USB MICRO USB charging interface

6 ----- Charging indicator light, turns red when charging, and turns off when full charged

7 ----- B, Bands switching

8 ----- CH, channel auto-searching



1 Power switch ● Pull the switch to turn on /off
2 Power indicator ● Turns blue after booting
3 S ● Click button “S” to switch channels between channel “1-8” when in 5.8G mode.
● Used as “+” when in setting menu
4 AV ● Switch to AV mode automatically when connect with AV devices, and will back to 5.8G mode when disconnect with AV device
5 USB ● For charging (DC 5V power)
6 Charging indicator light ●Turns red when charging, turns off when full charged
7 B

●Click button “B” to switch bands between “A,B, C, D, E, F” when in 5.8G mode

● Used as “-“ when in Setting menu

8 CH

●Click button “CH” to bring up Setting menu, and then click again to go to next menu.

● Long press to search channel automatically
