AV In FPV Drone Goggles 4.3" High Resolution TFT Large Size Monitor With Headband

AV In FPV Drone Goggles 4.3" High Resolution TFT Large Size Monitor With Headband
Features Gallery Product Description Request A Quote
AV IN: Support AV Vidoe Input
Resolution: 480*272
Screen Size: 4.3"
Magnification: 2.8x
Channles: 48CH
Power Consumption: 0.6W In AV In Mode, 1.8W In RF Mode
High Light:

drone fpv headset


fpv drone and goggles

Basic Infomation
Place of Origin: CHINA
Brand Name: ENMESI
Certification: CE, ROHS, FCC
Model Number: F2-A43
Payment & Shipping Terms
Packaging Details: gift box
Delivery Time: 3-7 working days
Payment Terms: T/T, Western Union etc
Supply Ability: 5000pcs/month
Product Description


4.3" High Resolution TFT Large Size Monitor With Headband, AV In FPV Drone Goggles



FPV is the abbreviation of English First Person View, which is “first person main perspective”. It is a new gameplay based on remote control aviation model or vehicle model with wireless camera backhaul equipment and screen control model on the ground. It allows users to experience the feeling of being on the plane.


UAVs generally refer to the drones with cameras, and those without cameras can only be regarded as toys. It is generally divided into two parts, one part is the remote control, the other part is the display part which is completed by the image transmission module. The signal transmitter is connected to the camera on the drone, and the signal receiver is in the hands of the player, and some are on the remote controller. Signal receive generally needs WIFI and 5.8GHZ radio signal, but the distance of WIFI is relatively not far, the player can use mobile phone to receive signals, but it will not be clear in the outdoor; and the 5.8GHZ radio signal, the distance can reach 2KM. It is best if within a few hundred meters, so most drones use 5.8GHZ radio signal.



Product Details:


Screen Size 4.3inch
Resolution 480*272
FOV Field of view: 0/120 degrees (horizontal / vertical)
Power consumption 1.5W in HD mode, 2.3W in 5.8G mode
Channels 48channesl (6 bands *8 channels), support channel auto-searching
Battery 600mAh reachargeable Li-battery
Size 150mmX82mmX145mm
Weight 280g



Product features


1.Extremely short reception delay.

2.High configuration:fast running speed,long duration,product light,clear screen,large storage capacity.

3.Beautiful design.

4.Comfortable:not only is the area in contact with the glasses comfortable,but the process of using the product is also comfortable.



48 channles as following


  Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8
Brand A 5645 5665 5685 5705 5885 5905 5925 5945
Brand B 5740 5760 5780 5800 5820 5840 5860 5880
Brand C 5725 5745 5765 5785 5805 5825 5845 5865
Brand D 5733 5752 5771 5790 5809 5828 5847 5866
Brand E 5658 5695 5732 5769 5809 5843 5880 5917

Short Delay Comfortable FPV Drone Goggles With AV In For Toys 4.3" Large Screen




It can be used as a display

a. for drone via 5.8G receiver

b.unmanned vehicles

c. night vision and such other products with AV in.


About us


Shenzhen Anpo Intelligence Technology Co., Ltd. was established in Shenzhen in the early 2014 and established its own factory (Dongguan Zhiyingshixun Technology Co., Ltd) in Dongguan with a total area of over 1,000 square meters., and the brand "ENMESI" was registered in the same year.


Enmesi is a professional solution provider for smart glasses integrated solutions in the fields of medical, education, industry, security, gaming and audio-visual entertainment. Its main research and development products include integrated solutions for head-mounted displays, 2D/3D intelligent video glasses, FPV aviator video glasses, VR/AR smart glasses, visual training glasses, night vision glasses, and micro display modules. According to the different needs of customers, Enmesi can provide customers with different solutions for smart glasses, providing OEM and ODM services.



Tag: fpv video goggles,fpv goggles video glasses
